FalzBook 1 – Pipes and Penetrations

Pages: 1038 Language: Russian / English Year of Publication: 2024 The book “Double-lock standing seam technology – Pipes & Penetrations” begins the series of books “Double-lock standing seam technology” and is intended for roofers, novice or expert, who specialize in the installation of double seam metal roofing as an auxiliary tool.   Double-lock standing seam technology is a system of rules, technological methods and nodes that allows you to implement the task of roofing from a flat metal sheet.  A “double fold system” is a set of elements that are in relationships and connections with each other and form a single whole. This system serves as a tool for studying the phenomena and processes occurring on a metal roof.   Chapter 1. Forming the connection of parts using a standing double seam. Direct placement of seams at the junction of parts of the abutment node. Chapter 2. Forming the connection of parts using a standing double seam. Diagonal placement of seams at the junction of parts of the abutment node. Chapter 3. Formation of an additional surface at the rear wall of the pipe to drain water. Cricket. Chapter 4. Forming the connection of parts using a lying double seam. Finnish and Swedish nodes. Chapter 5. Forming the connection of parts using a corner double seam. Chapter 6. A combination of corner and double seam tech-nologies when forming an abutment to pipes. Chapter 7. Forming an abutment to a round pipe. Chapter 8. Connection of abutment nodes with roofing parts. Chapter 9. Formation of parts of abutment nodes by laying folds on the surface of the workpiece. Origami method.
